Integrity tester WRTP-1000 for RTP

Description :

Medintegrity Aseptic lsolator Technology Solutions
Evaluating new aseptic handling/transfer technology
During sterle drug manufacure and formulafion,one of the most challenging aspects of manufacture is
the point at which ingredientsneed to be transferred into and out of a particular process while ensuring the integrity of the product and the critical area.

Compliance wih FDA21CFR part 11,EUAnnexl,and GAMP5
The user interface is friendly and allows the user an easy handing of the RTP integriy tesing
Medintegrity RTP test system can be integrated into other equipment, as well as into different type of ports:oval or circular with different diameters
Based on a well-established alphal/beta concept to allow for reliable and secured sterile transfer while maintaining the integrity of the critical area/isolators,RABS ,and clean rooms.

Get Price Contact

Integrity tester WRTP-1000 for RTP

Application :

Alpha Port: Transfer solutions from lower classified enviroments to higher classification process zones.

Beta Port：Transfer solutions from lower classified enviroments to higher classification process zones.

Installation Requiremnts ： Alpha Port : N/A

Beta port : Wall thickness 3-8mm If the wall thickness exceeds 8mm the accessories support is necessary

Parameters

Weight(approx.)	4kg+βport	4KG+αport
Operating Temp Ronge	5℃~30℃	5℃~30℃
Pressure Range	Posiive Pressure:30kPa Negafive Pressure:-30kPa	PositivePressure:30kPa Negative Pressure:-30kPa
Materials of Construction	StainlessSteel 316L/PETP/ Silicone/EPDM/PTFE	Slainless Steel 316L/PETP/ Silicone/EPDMPTFE
Available Diameter	190mm 270mm Customized	190mm 270mm Customized
Quality Standards	GMP/cGMP	GMP/CGMP
